Drawing template reference.
Title block, standard notes, default tolerances, GD&T frame templates, and revision conventions. Copy-paste-able language for your drawing template — and the standard format we expect on inbound drawings.
Sheet sizes
Standard ANSI and ISO sheet sizes.
| ANSI | Size (in) | ISO | Size (mm) | Typical use |
|---|---|---|---|---|
| A | 8.5 × 11 | A4 | 210 × 297 | Letter — small parts, parts list, simple components |
| B | 11 × 17 | A3 | 297 × 420 | Tabloid — moderate complexity parts |
| C | 17 × 22 | A2 | 420 × 594 | Standard CNC drawing for most parts |
| D | 22 × 34 | A1 | 594 × 841 | Large or complex parts, assemblies |
| E | 34 × 44 | A0 | 841 × 1189 | Large assemblies, weldments, layouts |
Title block
What every drawing needs in the bottom-right.
A standard title block contains everything needed to identify, manufacture, and inspect the part. The minimum required fields, plus what we’d like to see for clean handoff:
Standard notes
Copy-paste-able notes for your title block.
The below notes are common across CNC drawings — adjust to your standards. Every note that’s ambiguous on your drawing is a question we have to ask before we can quote.
Default tolerances
UNLESS OTHERWISE SPECIFIED: DECIMAL: .X = ±0.030, .XX = ±0.010, .XXX = ±0.005 ANGLE: ±0.5° FRACTIONAL: ±1/64 SURFACE FINISH: 125 µin Ra MAX ALL MACHINED EDGES: BREAK SHARP, ≤0.015 R/CHAMFER
Material callout
MATERIAL: 6061-T651 ALUMINUM PER AMS 4117 CERTIFIED MATERIAL TEST REPORT (CMTR) REQUIRED
Finish callout (anodized aluminum)
FINISH: TYPE II CLASS 2 ANODIZE PER MIL-A-8625 THICKNESS: 0.0005-0.0010 INCHES COLOR: BLACK MASK ALL THREADED HOLES AND PRESS-FIT BORES
Finish callout (passivated stainless)
FINISH: PASSIVATE PER AMS 2700 METHOD 2 (CITRIC ACID) ALL DIMENSIONS APPLY AFTER PASSIVATION
GD&T datum scheme
PRIMARY DATUM A: BOTTOM SURFACE SECONDARY DATUM B: BACK SURFACE TERTIARY DATUM C: LEFT SURFACE ALL POSITION TOLERANCES PER ASME Y14.5-2018
Inspection requirements
FIRST ARTICLE INSPECTION REQUIRED PER AS9102 FAI FORMS 1, 2, AND 3 TO ACCOMPANY FIRST SHIPMENT 100% INSPECTION FOR FEATURES MARKED *
ITAR / export control
THIS DRAWING CONTAINS TECHNICAL DATA SUBJECT TO ITAR (22 CFR 120-130). EXPORT, RE-EXPORT, OR DISCLOSURE TO FOREIGN PERSONS WITHOUT PRIOR DDTC AUTHORIZATION IS PROHIBITED.
DFARS specialty metals
ALL SPECIALTY METALS PER DFARS 252.225-7008/9. DOMESTIC MELT, POUR, AND FORGING REQUIRED. ORIGIN CERTIFICATION REQUIRED WITH SHIPMENT.
GD&T frame templates
Common feature control frames.
Position to 3 datums
⌖ ⌀.005 Ⓜ A B C
True position of a feature within 0.005 cylindrical zone, modified at MMC, datums A primary, B secondary, C tertiary.
Flatness on a face
⏥ .002
Surface must lie within two parallel planes 0.002 apart. No datum reference (form tolerance).
Perpendicularity to datum
⊥ .001 A
Feature axis perpendicular to datum A within 0.001. Common on locating features.
Profile of a surface
⌓ .005 A B
Surface shape constrained to 0.005 unilateral or bilateral profile relative to datums A and B.
Total runout
⌰ .002 A
Combined deviation of the entire feature surface as it rotates about datum A axis. Used on shafts.
Concentricity (legacy)
◎ ⌀.005 A
Note: removed from ASME Y14.5-2018 — use total runout or position to specify the same intent.
Revisions
Track every change.
Every released drawing should have a revision block listing every change since release. Revisions are typically lettered (A, B, C, …) starting at A or sometimes at “Initial”. The revision block lives next to the title block, usually in the upper-right.
- ·Letter the revision: A, B, C... (skip I, O, Q, S, X, Z to avoid confusion).
- ·Reference the change: ECN/DCN number tying the rev back to the change order.
- ·Date the change: ISO format YYYY-MM-DD recommended.
- ·Approver initials: Person who released the change.
- ·Description: “Changed material to 6061-T6” — short, clear, action-verb phrasing.
For aerospace/defense work, ECN-controlled drawings are required — every revision tied to a Change Notice document.
